STEEL PROTECTION SYSTEMS FOR ROADS

FILTERS

Retention level i The ability of the system to retain a certain type of vehicle.
Field of action i The distance from the starting point of the face of the guard in a normal state, to the farthest point the system went to during the impact // The largest displacement of the system from the starting position of the face of the fence to the farthest point of the system after the impact.
Shield type
ASI i The degree of severity of the impact on the persons in the vehicle.
Motorcyclist landing protection
System type
Mounting type
System width

0.00 m - 1.00 m

Dynamic deflection i The distance between the starting point of the face of the shield in a normal state, and the face of the shield during impact.

0.0 m - 3.0 m

Vehicle penetration (m')

0.0 m - 5.0 m

Field of action

0.00 m - 3.00 m

The number of displayed items is: 93


* Select products by clicking on the star and print, compare or send as a request for a quote to our sales department.

slika
×
System name ESP/4.0
Retention level N2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W5
Dynamic deflection 1.6 m
ASI A
Vehicle penetration /

Tested length 60 m
System width 0.18 m
The depth of the pile 1,20 m
Field of action 1.7 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name ESP/2.0
Retention level N2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W4
Dynamic deflection 1.2 m
ASI A
Vehicle penetration /

Tested length 60 m
System width 0.18 m
The depth of the pile 1,20 m
Field of action 1.3 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name ESP Plus/2.0
Retention level N2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W4
Dynamic deflection 1.1 m
ASI A
Vehicle penetration /

Tested length 60 m
System width 0.18 m
The depth of the pile 1,20 m
Field of action 1.2 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name ESP Plus W1
Retention level N2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W1
Dynamic deflection 0.5 m
ASI B
Vehicle penetration /

Tested length 40 m
System width 0.18 m
The depth of the pile 1,20 m
Field of action 0.6 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name SUPER RAIL ES/1.0
Retention level N2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W2
Dynamic deflection 0.5 m
ASI A
Vehicle penetration /

Tested length 40 m
System width 0.18 m
The depth of the pile 1.05 m
Field of action 0.7 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name SUPER RAIL ES/1.33
Retention level N2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W2
Dynamic deflection 0.7 m
ASI A
Vehicle penetration /

Tested length 60 m
System width 0.18 m
The depth of the pile 1.05 m
Field of action 0.8 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name Eco-Safe/4.0
Retention level N2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W5
Dynamic deflection 1.6 m
ASI A
Vehicle penetration /

Tested length 48 m
System width 0.14 m
The depth of the pile 1,00 m
Field of action 1.7 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name Eco-Safe/2.0 MPS
Retention level N2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W3
Dynamic deflection 0.9 m
ASI A
Vehicle penetration /

Tested length 48 m
System width 0.14 m
The depth of the pile 1,00 m
Field of action 1.0 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name Eco-Safe/1.33 MPS
Retention level N2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W3
Dynamic deflection 0.8 m
ASI A
Vehicle penetration /

Tested length 48 m
System width 0.14 m
The depth of the pile 1,00 m
Field of action 0.9 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name ESP/4.0 UFS
Retention level N2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W5
Dynamic deflection 1.4 m
ASI A
Vehicle penetration /

Tested length 60 m
System width 0.18 m
The depth of the pile 1,20 m
Field of action 1.6 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name ESP BOS
Retention level N2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W3
Dynamic deflection 0.2 m
ASI B
Vehicle penetration /

Tested length 20 m
System width 0.86 m
The depth of the pile 1,20 m
Field of action 0.9 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNI RAIL 1.33 H2 W5 TYPE B
Retention level N2
Place of installation Embankment/Bank
Shield type Shield B
Field of action W3
Dynamic deflection 0.9 m
ASI A
Vehicle penetration /

Tested length 44 m
System width 0.21 m
The depth of the pile 0,96 m
Field of action 1.0 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNI RAIL PLUS 1.00
Retention level N2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W1
Dynamic deflection 0.3 m
ASI B
Vehicle penetration /

Tested length 60 m
System width 0.34 m
The depth of the pile 0,80 m
Field of action 0.6 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name EDSP/1.33
Retention level H1
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W4
Dynamic deflection 1.1 m
ASI A
Vehicle penetration 2 m

Tested length 60 m
System width 0.5 m
The depth of the pile 1.28 m
Field of action 1.2 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name SUPER RAIL ES/1.0
Retention level L1
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W2
Dynamic deflection 0.7 m
ASI A
Vehicle penetration 1.4 m

Tested length 40 m
System width 0.21 m
The depth of the pile 1.05 m
Field of action 0.8 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name SUPER RAIL ES/1.33
Retention level L1
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W4
Dynamic deflection 1 m
ASI A
Vehicle penetration 1.3 m

Tested length 60 m
System width 0.21 m
The depth of the pile 1.05 m
Field of action 1.1 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name Eco-Safe/2.0 MPS
Retention level L1
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W4
Dynamic deflection 1.2 m
ASI A
Vehicle penetration 2.1 m

Tested length 48 m
System width 0.14 m
The depth of the pile 1.00 m
Field of action 1.3 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name Eco-Safe/1.3 MPS
Retention level L1
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W3
Dynamic deflection 0.8 m
ASI A
Vehicle penetration 2.2 m

Tested length 48 m
System width 0.14 m
The depth of the pile 1.00 m
Field of action 1.0 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name DDSP/4.0 doppelt
Retention level H1
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W6
Dynamic deflection 1.8 m
ASI A
Vehicle penetration 2.1 m

Tested length 60 m
System width 0.8 m
The depth of the pile 1.28 m
Field of action 1.9 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNIRAIL 3.0 H1W3
Retention level H1
Place of installation Embankment/Bank
Shield type Shield B
Field of action W3
Dynamic deflection 0.9 m
ASI A
Vehicle penetration 1.2 m

Tested length 49.5 m
System width 0.21 m
The depth of the pile 0.89 m
Field of action 1.0 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNIRAIL 1.33 TYPE B
Retention level L1
Place of installation Embankment/Bank
Shield type Shield B
Field of action W4
Dynamic deflection 1.1 m
ASI A
Vehicle penetration 1.7 m

Tested length 44 m
System width 0.21 m
The depth of the pile 0.96 m
Field of action 1.2 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNIRAIL 2.66
Retention level H1
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W4
Dynamic deflection 1 m
ASI A
Vehicle penetration 2 m

Tested length 54.0 m
System width 0.21 m
The depth of the pile 0.98 m
Field of action 1.2 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name EDSP/2.0
Retention level H2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W8
Dynamic deflection 2.9 m
ASI A
Vehicle penetration /

Tested length 68 m
System width 0.5 m
The depth of the pile 1.28 m
Field of action 3.2 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name DDSP/2.0++ doppelt
Retention level H2
Place of installation Embankment/Bank
Shield type Shield A
Field of action W6
Dynamic deflection 1.7 m
ASI A
Vehicle penetration 2.1 m

Tested length 80 m
System width 0.8 m
The depth of the pile 1.28 m
Field of action 1.9 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name SUPER RAIL
Retention level L2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W4
Dynamic deflection 0.8 m
ASI A
Vehicle penetration 1.3 m

Tested length 40 m
System width 0.5 m
The depth of the pile 1.26 m
Field of action 1.3 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name SUPER RAIL VZB
Retention level L2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W3
Dynamic deflection 0.5 m
ASI B
Vehicle penetration 0.9 m

Tested length 28 m
System width 0.5 m
The depth of the pile 1.26 m
Field of action 0.9 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name SUPER RAIL doppelt
Retention level L2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W4
Dynamic deflection 0.6 m
ASI B
Vehicle penetration 1 m

Tested length 60 m
System width 0.86 m
The depth of the pile 1.26 m
Field of action 1.2 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name SUPER RAIL Eco
Retention level L2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W4
Dynamic deflection 0.7 m
ASI A
Vehicle penetration 1.3 m

Tested length 52 m
System width 0.45 m
The depth of the pile 1.01 m
Field of action 1.3 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name SUPER RAIL Eco doppelt
Retention level L2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W4
Dynamic deflection 0.7 m
ASI B
Vehicle penetration 1.4 m

Tested length 52 m
System width 0.45 m
The depth of the pile 1.01 m
Field of action 1.2 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name SUPER RAIL Eco MUF
Retention level L2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W4
Dynamic deflection 1.1 m
ASI A
Vehicle penetration 1.4 m

Tested length 52 m
System width 0.45 m
The depth of the pile 1.01 m
Field of action 1.3 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name SUPER RAIL Eco HS
Retention level L2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W2
Dynamic deflection 0.6 m
ASI B
Vehicle penetration 0.8 m

Tested length 36 m
System width 0.37 m
The depth of the pile 1.05 m
Field of action 0.8 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name SUPER RAIL Light
Retention level H2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W5
Dynamic deflection 1.1 m
ASI B
Vehicle penetration 2.4 m

Tested length 52 m
System width 0.45 m
The depth of the pile 1.11 m
Field of action 1.5 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNI RAIL 3W 1.5
Retention level H2
Place of installation Embankment/Bank
Shield type Troval shield
Field of action W3
Dynamic deflection 0.9 m
ASI B
Vehicle penetration 1 m

Tested length 45 m
System width 0.29 m
The depth of the pile 0.87 m
Field of action 1.0 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNI RAIL 3W 2.0
Retention level H2
Place of installation Embankment/Bank
Shield type Troval shield
Field of action W5
Dynamic deflection 1.6 m
ASI A
Vehicle penetration 2.1 m

Tested length 40 m
System width 0.35 m
The depth of the pile 1.00 m
Field of action 1.7 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name SUPER RAIL HS
Retention level L2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W3
Dynamic deflection 0.5 m
ASI B
Vehicle penetration 0.8 m

Tested length 60 m
System width 0.45 m
The depth of the pile 1.11 m
Field of action 0.9 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNI RAIL 1.33 TYPE B
Retention level L2
Place of installation Embankment/Bank
Shield type Shield B
Field of action W5
Dynamic deflection 1.5 m
ASI A
Vehicle penetration 1.6 m

Tested length 44 m
System width 0.21 m
The depth of the pile 0.96 m
Field of action 1.6 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNI RAIL 1.33 TYPE A
Retention level H2
Place of installation Embankment/Bank
Shield type Shield A
Field of action W5
Dynamic deflection 1.6 m
ASI A
Vehicle penetration 2.3 m

Tested length 44 m
System width 0.21 m
The depth of the pile 0.96 m
Field of action 1.7 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNI RAIL PLUS 1.33
Retention level H2
Place of installation Embankment/Bank
Shield type Shield B
Field of action W3
Dynamic deflection 0.9 m
ASI B
Vehicle penetration 1.5 m

Tested length 44 m
System width 0.21 m
The depth of the pile 0.79 m
Field of action 1.0 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNI RAIL ULTRA 3W 1.5
Retention level H2
Place of installation Embankment/Bank
Shield type Troval shield
Field of action W2
Dynamic deflection 0.7 m
ASI B
Vehicle penetration 1.5 m

Tested length 49 m
System width 0.29 m
The depth of the pile 0.87 m
Field of action 0.8 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNI RAIL PLUS 1.00
Retention level L2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W2
Dynamic deflection 0.6 m
ASI B
Vehicle penetration 1.4 m

Tested length 60 m
System width 0.34 m
The depth of the pile 0.80 m
Field of action 0.8 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name SUPER RAIL
Retention level L4b
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W7
Dynamic deflection 2 m
ASI A
Vehicle penetration 2.5 m

Tested length 76 m
System width 0.5 m
The depth of the pile 1.16 m
Field of action 2.3 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name SUPER RAIL doppelt
Retention level L4b
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W5
Dynamic deflection 0.9 m
ASI B
Vehicle penetration 3.4 m

Tested length 60 m
System width 0.86 m
The depth of the pile 1.26 m
Field of action 1.5 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name SUPER RAIL Pro
Retention level L4b
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W4
Dynamic deflection 1.1 m
ASI B
Vehicle penetration 3.6 m

Tested length 60 m
System width 0.32 m
The depth of the pile 1.01 m
Field of action 1.3 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name SUPER RAIL HS
Retention level L4b
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W4
Dynamic deflection 0.9 m
ASI B
Vehicle penetration 3.3 m

Tested length 60 m
System width 0.45 m
The depth of the pile 1.11 m
Field of action 1.2 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name SUPER RAIL Eco HS
Retention level L4b
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W4
Dynamic deflection 0.9 m
ASI B
Vehicle penetration 4.1 m

Tested length 80 m
System width 0.37 m
The depth of the pile 1.05 m
Field of action 1.1 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name Eco Safe 1.33 Bw
Retention level N2
Place of installation On the bridge/Concrete
Shield type Shield A and Shield B
Field of action W1
Dynamic deflection 0.5 m
ASI A
Vehicle penetration 0 m

Tested length 36 m
System width 0.3 m
The depth of the pile 0.125 m
Field of action 0.6 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name Eco-Safe 1.33 Bw
Retention level L1
Place of installation On the bridge/Concrete
Shield type Shield A and Shield B
Field of action W2
Dynamic deflection 0.6 m
ASI A
Vehicle penetration 2.4 m

Tested length 36 m
System width 0.3 m
The depth of the pile 0.125 m
Field of action 0.8 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name SUPER RAIL Bw
Retention level L2
Place of installation On the bridge/Concrete
Shield type Shield A and Shield B
Field of action W4
Dynamic deflection 0.6 m
ASI B
Vehicle penetration 1.2 m

Tested length 36 m
System width 0.5 m
The depth of the pile 0.125 m
Field of action 1.2 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name SUPER RAIL Bw doppelt
Retention level L2
Place of installation On the bridge/Concrete
Shield type Shield A and Shield B
Field of action W4
Dynamic deflection 0.6 m
ASI B
Vehicle penetration 1.2 m

Tested length 36 m
System width 0.86 m
The depth of the pile 0.125 m
Field of action 1.2 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name SUPER RAIL Eco Bw
Retention level L2
Place of installation On the bridge/Concrete
Shield type Shield A and Shield B
Field of action W4
Dynamic deflection 0.9 m
ASI A
Vehicle penetration 1.4 m

Tested length 60 m
System width 0.45 m
The depth of the pile 0.125 m
Field of action 1.3 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name SUPER RAIL Light Bw
Retention level H2
Place of installation On the bridge/Concrete
Shield type
Field of action W4
Dynamic deflection 0.8 m
ASI B
Vehicle penetration 1.4 m

Tested length 36 m
System width 0.45 m
The depth of the pile 0.125 m
Field of action 1.3 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name SUPER RAIL Eco Bw doppelt
Retention level L2
Place of installation On the bridge/Concrete
Shield type Shield A and Shield B
Field of action W4
Dynamic deflection 0.9 m
ASI B
Vehicle penetration 1.4 m

Tested length 60 m
System width 0.7 m
The depth of the pile 0.125 m
Field of action 1.3 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name SUPER RAIL Eco HS Bw
Retention level L2
Place of installation On the bridge/Concrete
Shield type Shield A and Shield B
Field of action W1
Dynamic deflection 0.4 m
ASI B
Vehicle penetration 0.7 m

Tested length 36 m
System width 0.37 m
The depth of the pile 0.125 m
Field of action 0.5 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name SUPER RAIL HS Bw
Retention level L2
Place of installation On the bridge/Concrete
Shield type Shield A and Shield B
Field of action W2
Dynamic deflection 0.4 m
ASI B
Vehicle penetration 0.8 m

Tested length 60 m
System width 0.45 m
The depth of the pile 0.125 m
Field of action 0.8 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNI RAIL PLUS 1.33 BW
Retention level H2
Place of installation On the bridge/Concrete
Shield type Shield A and Shield B
Field of action W3
Dynamic deflection 0.7 m
ASI B
Vehicle penetration 1.3 m

Tested length 44 m
System width 0.34 m
The depth of the pile 0.125 m
Field of action 1.0 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNI RAIL 3W 1.5 BW
Retention level H2
Place of installation On the bridge/Concrete
Shield type Troval shield
Field of action W4
Dynamic deflection 1.1 m
ASI B
Vehicle penetration 1.2 m

Tested length 54 m
System width 0.34 m
The depth of the pile 0.190 m
Field of action 1.2 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name SUPER RAIL Plus Bw
Retention level H4b
Place of installation On the bridge/Concrete
Shield type Shield A and Shield B
Field of action W6
Dynamic deflection 1.2 m
ASI B
Vehicle penetration >3,5 m

Tested length 80 m
System width 0.6 m
The depth of the pile 0.125 m
Field of action 2.1 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name SUPER RAIL Pro Bw
Retention level L4b
Place of installation On the bridge/Concrete
Shield type Shield A and Shield B
Field of action W2
Dynamic deflection 0.3 m
ASI B
Vehicle penetration 1.7 m

Tested length 72 m
System width 0.32 m
The depth of the pile 0.125 m
Field of action 0.7 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name SUPER RAIL HS Bw
Retention level L4b
Place of installation On the bridge/Concrete
Shield type Shield A and Shield B
Field of action W4
Dynamic deflection 0.9 m
ASI B
Vehicle penetration 4.2 m

Tested length 60 m
System width 0.45 m
The depth of the pile 0.125 m
Field of action 1.3 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name EDSP/2.0
Retention level H1
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W5
Dynamic deflection 1.3 m
ASI A
Vehicle penetration 2.3 m

Tested length 60 m
System width 0.5 m
The depth of the pile 1.28 m
Field of action 1.7 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name Eco-Safe/2.0
Retention level N2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W3
Dynamic deflection 0.9 m
ASI A
Vehicle penetration 0 m

Tested length 48 m
System width 0.14 m
The depth of the pile 1,00 m
Field of action 1.0 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name Eco-Safe/1.33
Retention level N2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W3
Dynamic deflection 0.8 m
ASI A
Vehicle penetration 0 m

Tested length 48 m
System width 0.14 m
The depth of the pile 1,00 m
Field of action 0.9 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name Eco-Safe/2.0
Retention level L1
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W4
Dynamic deflection 1.2 m
ASI A
Vehicle penetration 2.1 m

Tested length 48 m
System width 0.14 m
The depth of the pile 1.00 m
Field of action 1.3 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name Eco-Safe/1.33
Retention level L1
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W3
Dynamic deflection 0.8 m
ASI A
Vehicle penetration 2.2 m

Tested length 48 m
System width 0.14 m
The depth of the pile 1.00 m
Field of action 1.0 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNISAFE 2.66
Retention level N2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W3
Dynamic deflection 1 m
ASI A
Vehicle penetration /

Tested length 64 m
System width 0.21 m
The depth of the pile 0.85 m
Field of action 1.0 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNISAFE LIGHT 4.0
Retention level N2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W5
Dynamic deflection 1.4 m
ASI A
Vehicle penetration /

Tested length 64 m
System width 0.21 m
The depth of the pile 0.85 m
Field of action 1.4 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNISAFE EASY 4.0
Retention level N2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W5
Dynamic deflection 1.5 m
ASI A
Vehicle penetration /

Tested length 64 m
System width 0.21 m
The depth of the pile 0.95 m
Field of action 1.6 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNISAFE 1.33
Retention level H1
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W3
Dynamic deflection 1.5 m
ASI A
Vehicle penetration 1 m

Tested length 80 m
System width 0.21 m
The depth of the pile 0.85 m
Field of action 1.0 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNISAFE LIGHT 2.0
Retention level N2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W2
Dynamic deflection 0.8 m
ASI A
Vehicle penetration /

Tested length 64 m
System width 0.21 m
The depth of the pile 0.85 m
Field of action 0.8 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNISAFE EASY 2.0
Retention level N2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W3
Dynamic deflection 1 m
ASI A
Vehicle penetration /

Tested length 64 m
System width 0.21 m
The depth of the pile 0.95 m
Field of action 1.0 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNISAFE LIGHT 2.66
Retention level N2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action Table
Dynamic deflection 0.7 m
ASI A
Vehicle penetration /

Tested length 88 m
System width 0.21 m
The depth of the pile 0.95 m
Field of action 0.8 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNISAFE 4.0
Retention level N2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W4
Dynamic deflection 1.2 m
ASI A
Vehicle penetration /

Tested length 56 m
System width 0.21 m
The depth of the pile 0.85 m
Field of action 1.2 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNISAFE 2.0
Retention level H1
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W3
Dynamic deflection 0.9 m
ASI A
Vehicle penetration 3.3 m

Tested length 56 m
System width 0.21 m
The depth of the pile 1.04 m
Field of action 1.0 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNISAFE 2.0 BW
Retention level H1
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W2
Dynamic deflection 0.7 m
ASI A
Vehicle penetration 2.8 m

Tested length 68 m
System width 0.21 m
The depth of the pile 0.125 m
Field of action 0.8 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNISAFE 3W 2.66
Retention level H2
Place of installation Embankment/Bank
Shield type Troval shield
Field of action W4
Dynamic deflection 1.1 m
ASI A
Vehicle penetration 1.5 m

Tested length 72 m
System width 0.21 m
The depth of the pile 0.9 m
Field of action 1.2 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNISAFE SM 3W 2.00
Retention level H2
Place of installation Embankment/Bank
Shield type Troval shield
Field of action W3
Dynamic deflection 0.5 m
ASI A
Vehicle penetration 1.2 m

Tested length 48 m
System width 0.31 m
The depth of the pile 0.85 m
Field of action 0.9 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNISAFE LIGHT 3W 2.00 BW
Retention level H2
Place of installation Embankment/Bank
Shield type Troval shield
Field of action W4
Dynamic deflection 0.9 m
ASI B
Vehicle penetration 1.7 m

Tested length 52 m
System width 0.21 m
The depth of the pile 0.165 m
Field of action 1.24 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNISAFE 3W 2.00 BW
Retention level H2
Place of installation Embankment/Bank
Shield type Troval shield
Field of action W3
Dynamic deflection 0.6 m
ASI B
Vehicle penetration 0.9 m

Tested length 52 m
System width 0.315 m
The depth of the pile 0.165 m
Field of action 1.0 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNISAFE SM 3W 2.00 BW
Retention level H2
Place of installation Embankment/Bank
Shield type Troval shield
Field of action W3
Dynamic deflection 0.7 m
ASI B
Vehicle penetration 1.1 m

Tested length 48 m
System width 0.315 m
The depth of the pile 0.25 m
Field of action 1.0 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNISAFE SM 3W 1.33 BW
Retention level H2
Place of installation Embankment/Bank
Shield type Troval shield
Field of action W3
Dynamic deflection 0.6 m
ASI B
Vehicle penetration 1.1 m

Tested length 48 m
System width 0.33 m
The depth of the pile 0.25 m
Field of action 0.8 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNISAFE DOUBLE 1.33
Retention level H2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W3
Dynamic deflection 0.9 m
ASI B
Vehicle penetration 1.42 m

Tested length 80 m
System width 0.31 m
The depth of the pile 0.92 m
Field of action 1.0 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNISAFE DOUBLE 2.0
Retention level H2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W5
Dynamic deflection 1.6 m
ASI A
Vehicle penetration 2 m

Tested length 80 m
System width 0.28 m
The depth of the pile 0.93 m
Field of action 1.7 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNISAFE M DOUBLE 1.33
Retention level H2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W2
Dynamic deflection 0.5 m
ASI B
Vehicle penetration 1 m

Tested length 52 m
System width 0.41 m
The depth of the pile 1.0 m
Field of action 0.8 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNISAFE LIGHT DOUBLE 2.0
Retention level H2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W4
Dynamic deflection 1.2 m
ASI A
Vehicle penetration 1.9 m

Tested length 52 m
System width 0.26 m
The depth of the pile 1.04 m
Field of action 1.3 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNISAFE DOUBLE 1.33 BW
Retention level H2
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W2
Dynamic deflection 0.4 m
ASI B
Vehicle penetration 0.9 m

Tested length 52 m
System width 0.41 m
The depth of the pile 0.165 m
Field of action 0.8 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNISAFE PRO 3W 2.0
Retention level H3
Place of installation Embankment/Bank
Shield type Troval shield
Field of action W5
Dynamic deflection 1.3 m
ASI A
Vehicle penetration 2.8 m

Tested length 81 m
System width 0.41 m
The depth of the pile 1.01 m
Field of action 1.4 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNISAFE PRO 3W 2.0 BW
Retention level H4b
Place of installation Embankment/Bank
Shield type Troval shield
Field of action W3
Dynamic deflection 0.7 m
ASI A
Vehicle penetration 2.3 m

Tested length 81 m
System width 0.55 m
The depth of the pile 0.175 m
Field of action 1.0 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNISAFE EASY 2.0
Retention level H1
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W4
Dynamic deflection 1.2 m
ASI A
Vehicle penetration 2.3 m

Tested length 40 m
System width 0.21 m
The depth of the pile 0.95 m
Field of action 1.3 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNISAFE PRO 3W 2.0
Retention level H4b
Place of installation Embankment/Bank
Shield type Troval shield
Field of action W5
Dynamic deflection 1.6 m
ASI A
Vehicle penetration 1.6 m

Tested length 81 m
System width 0.55 m
The depth of the pile 1.01 m
Field of action 1.7 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNISAFE LIGHT 2.0
Retention level H1
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W4
Dynamic deflection 1 m
ASI A
Vehicle penetration 1.8 m

Tested length 64 m
System width 0.21 m
The depth of the pile 0.85 m
Field of action 1.0 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNISAFE LIGHT 2.66
Retention level H1
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W3
Dynamic deflection 0.9 m
ASI A
Vehicle penetration 1.7 m

Tested length 88 m
System width 0.21 m
The depth of the pile 0.95 m
Field of action 0.9 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNISAFE 4.0
Retention level H1
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W4
Dynamic deflection 1.2 m
ASI A
Vehicle penetration 2.7 m

Tested length 56 m
System width 0.21 m
The depth of the pile 0.85 m
Field of action 1.2 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
slika
×
System name UNISAFE 1.33 BW
Retention level H1
Place of installation Embankment/Bank
Shield type Shield A and Shield B
Field of action W1
Dynamic deflection 0.3 m
ASI A
Vehicle penetration 1.1 m

Tested length 68 m
System width 0.21 m
The depth of the pile 0.125 m
Field of action 0.5 m
Technical drawing in PDF format
Technical drawing in DWG format
Certificate of Consistency of Performance
Chat
Chat
Need help?

If you have questions or need additional support, contact us! Our team will answer you as soon as possible.
